The console widget is a scrolling text widget used primarily for logging purposes and "terminals" It is high-performance and features bounded but arbitrary scroll-back capability. More...
#include <FXConsole.h>
Public Types | |
| enum | { ID_XXX = FXScrollArea::ID_LAST, ID_LAST } |
Public Member Functions | |
| long | onPaint (FXObject *, FXSelector, void *) |
| long | onXXX (FXObject *, FXSelector, void *) |
| FXConsole (FXComposite *p, FXObject *tgt=NULL, FXSelector sel=0, FXuint opts=0, FXint x=0, FXint y=0, FXint w=0, FXint h=0, FXint pl=3, FXint pr=3, FXint pt=2, FXint pb=2) | |
| Construct console window. | |
| virtual void | create () |
| Create server-side resources. | |
| virtual void | detach () |
| Detach server-side resources. | |
| virtual void | layout () |
| Perform layout. | |
| virtual FXint | getDefaultWidth () |
| Return default width. | |
| virtual FXint | getDefaultHeight () |
| Return default height. | |
| virtual FXbool | canFocus () const |
| Returns true because a text widget can receive focus. | |
| virtual FXint | getContentWidth () |
| Return content width. | |
| virtual FXint | getContentHeight () |
| Return content height. | |
| void | setFont (FXFont *fnt) |
| Change text font. | |
| FXFont * | getFont () const |
| Return text font. | |
| void | setMarginTop (FXint pt) |
| Change top margin. | |
| FXint | getMarginTop () const |
| Return top margin. | |
| void | setMarginBottom (FXint pb) |
| Change bottom margin. | |
| FXint | getMarginBottom () const |
| Return bottom margin. | |
| void | setMarginLeft (FXint pl) |
| Change left margin. | |
| FXint | getMarginLeft () const |
| Return left margin. | |
| void | setMarginRight (FXint pr) |
| Change right margin. | |
| FXint | getMarginRight () const |
| Return right margin. | |
| void | setHistoryLines (FXint hl) |
| Change history lines. | |
| FXint | getHistoryLines () const |
| Return history lines. | |
| void | setVisibleRows (FXint rows) |
| Change number of visible rows. | |
| FXint | getVisibleRows () const |
| Return number of visible rows. | |
| void | setVisibleColumns (FXint cols) |
| Change number of visible columns. | |
| FXint | getVisibleColumns () const |
| Return number of visible columns. | |
| void | setHelpText (const FXString &text) |
| Set help text. | |
| FXString | getHelpText () const |
| Return help text. | |
| void | setTipText (const FXString &text) |
| Set the tool tip message for this widget. | |
| FXString | getTipText () const |
| Get the tool tip message for this widget. | |
| virtual void | save (FXStream &store) const |
| Save to a stream. | |
| virtual void | load (FXStream &store) |
| Load from a stream. | |
| virtual | ~FXConsole () |
| Destructor. | |
Protected Types | |
| enum | { STYLE_MASK = 0x00FF, STYLE_TEXT = 0x0100, STYLE_SELECTED = 0x0200, STYLE_CONTROL = 0x0400, STYLE_HILITE = 0x0800, STYLE_ACTIVE = 0x1000 } |
Protected Member Functions | |
| FXint | charWidth (FXwchar ch, FXint col) const |
| FXuint | styleOf (FXint line, FXint index, FXint p, FXint c) const |
| virtual void | moveContents (FXint x, FXint y) |
| void | drawTextFragment (FXDCWindow &dc, FXint x, FXint y, FXint w, FXint h, const FXchar *text, FXint n, FXuint sty) const |
| void | drawTextLine (FXDCWindow &dc, FXint line, FXint left, FXint right) const |
| void | drawContents (FXDCWindow &dc, FXint x, FXint y, FXint w, FXint h) const |
Protected Attributes | |
| FXStringBuffer | contents |
| FXStringBuffer | style |
| FXFont * | font |
| FXint | margintop |
| FXint | marginbottom |
| FXint | marginleft |
| FXint | marginright |
| FXint | historylines |
| FXint | visiblelines |
| FXint | topline |
| FXint | vrows |
| FXint | vcols |
| FXColor | textColor |
| FXColor | selbackColor |
| FXColor | seltextColor |
| FXColor | cursorColor |
| FXString | help |
| FXString | tip |
The console widget is a scrolling text widget used primarily for logging purposes and "terminals" It is high-performance and features bounded but arbitrary scroll-back capability.
|
