The Dial widget is a valuator widget which is able to provide a cyclic value range when the DIAL_CYCLIC is passed, or a simple linear value range. More...
#include <FXDial.h>
Public Member Functions | |
| long | onPaint (FXObject *, FXSelector, void *) |
| long | onMotion (FXObject *, FXSelector, void *) |
| long | onMouseWheel (FXObject *, FXSelector, void *) |
| long | onLeftBtnPress (FXObject *, FXSelector, void *) |
| long | onLeftBtnRelease (FXObject *, FXSelector, void *) |
| long | onKeyPress (FXObject *, FXSelector, void *) |
| long | onKeyRelease (FXObject *, FXSelector, void *) |
| long | onUngrabbed (FXObject *, FXSelector, void *) |
| long | onCmdSetValue (FXObject *, FXSelector, void *) |
| long | onCmdSetIntValue (FXObject *, FXSelector, void *) |
| long | onCmdGetIntValue (FXObject *, FXSelector, void *) |
| long | onCmdSetLongValue (FXObject *, FXSelector, void *) |
| long | onCmdGetLongValue (FXObject *, FXSelector, void *) |
| long | onCmdSetRealValue (FXObject *, FXSelector, void *) |
| long | onCmdGetRealValue (FXObject *, FXSelector, void *) |
| long | onCmdSetIntRange (FXObject *, FXSelector, void *) |
| long | onCmdGetIntRange (FXObject *, FXSelector, void *) |
| long | onCmdSetRealRange (FXObject *, FXSelector, void *) |
| long | onCmdGetRealRange (FXObject *, FXSelector, void *) |
| long | onCmdSetHelp (FXObject *, FXSelector, void *) |
| long | onCmdGetHelp (FXObject *, FXSelector, void *) |
| long | onCmdSetTip (FXObject *, FXSelector, void *) |
| long | onCmdGetTip (FXObject *, FXSelector, void *) |
| long | onQueryHelp (FXObject *, FXSelector, void *) |
| long | onQueryTip (FXObject *, FXSelector, void *) |
| FXDial (FXComposite *p, FXObject *tgt=NULL, FXSelector sel=0, FXuint opts=DIAL_NORMAL, FXint x=0, FXint y=0, FXint w=0, FXint h=0, FXint pl=DEFAULT_PAD, FXint pr=DEFAULT_PAD, FXint pt=DEFAULT_PAD, FXint pb=DEFAULT_PAD) | |
| Construct a dial widget. | |
| virtual FXint | getDefaultWidth () |
| Return default width. | |
| virtual FXint | getDefaultHeight () |
| Return default height. | |
| virtual FXbool | canFocus () const |
| Returns true because a dial can receive focus. | |
| void | setValue (FXint value, FXbool notify=false) |
| Set the dial value. | |
| FXint | getValue () const |
| Return the dial value. | |
| void | setRange (FXint lo, FXint hi, FXbool notify=false) |
| Change the dial's range. | |
| void | getRange (FXint &lo, FXint &hi) const |
| Obtain the current range of the dial. | |
| void | setRevolutionIncrement (FXint i) |
| Set the revolution increment, which is the amount of change in the position for revolution of the dial; the dial may go through multiple revolutions to go through its whole range; by default it takes one 360 degree turn of the dial to go from the lower to the upper range. | |
| FXint | getRevolutionIncrement () const |
| Get the current value of the revolution increment. | |
| void | setNotchSpacing (FXint spacing) |
| Change the spacing for the small notches; this should be set in tenths of degrees in the range [1,3600], and the value should be a divisor of 3600, so as to make the notches come out evenly. | |
| FXint | getNotchSpacing () const |
| Get the current notch spacing. | |
| void | setNotchOffset (FXint offset) |
| Change the notch offset, which is the position of the center notch; the value should be tenths of degrees in the range [-3600,3600]. | |
| FXint | getNotchOffset () const |
| Get the current center notch offset. | |
| void | setDialStyle (FXuint opts) |
| Changes the dial style. | |
| FXuint | getDialStyle () const |
| Get the current dial style. | |
| void | setNotchColor (FXColor clr) |
| Change the center notch color. | |
| FXColor | getNotchColor () const |
| Get the current center notch color. | |
| void | setHelpText (const FXString &text) |
| Set the help text to be displayed on the status line. | |
| const FXString & | getHelpText () const |
| Get the current help text. | |
| void | setTipText (const FXString &text) |
| Set the tip text to be displayed in the tooltip. | |
| const FXString & | getTipText () const |
| Get the current tooltip text value. | |
| virtual void | save (FXStream &store) const |
| Save to stream. | |
| virtual void | load (FXStream &store) |
| Load from stream. | |
Protected Attributes | |
| FXint | notchAngle |
| FXint | notchSpacing |
| FXint | notchOffset |
| FXColor | notchColor |
| FXint | dragPoint |
| FXint | dragPos |
| FXint | range [2] |
| FXint | incr |
| FXint | pos |
| FXString | help |
| FXString | tip |
The Dial widget is a valuator widget which is able to provide a cyclic value range when the DIAL_CYCLIC is passed, or a simple linear value range.
While being turned, the dial sends a SEL_CHANGED message to its target; at the end of the interaction, a SEL_COMMAND message is sent. The message data represents the current value, of type FXint. The options DIAL_VERTICAL and DIAL_HORIZONTAL control the orientation of the dial. An optional notch can be used to indicate the zero-position of the dial; display of the notch is controlled by the DIAL_HAS_NOTCH option.
|
