Seven-segment (eg LCD/watch style) widget, useful for making indicators and timers. More...
#include <FX7Segment.h>
Public Member Functions | |
| long | onPaint (FXObject *, FXSelector, void *) |
| long | onCmdSetValue (FXObject *, FXSelector, void *) |
| long | onCmdSetIntValue (FXObject *, FXSelector, void *) |
| long | onCmdGetIntValue (FXObject *, FXSelector, void *) |
| long | onCmdSetLongValue (FXObject *, FXSelector, void *) |
| long | onCmdGetLongValue (FXObject *, FXSelector, void *) |
| long | onCmdSetRealValue (FXObject *, FXSelector, void *) |
| long | onCmdGetRealValue (FXObject *, FXSelector, void *) |
| long | onCmdSetStringValue (FXObject *, FXSelector, void *) |
| long | onCmdGetStringValue (FXObject *, FXSelector, void *) |
| long | onCmdSetHelp (FXObject *, FXSelector, void *) |
| long | onCmdGetHelp (FXObject *, FXSelector, void *) |
| long | onCmdSetTip (FXObject *, FXSelector, void *) |
| long | onCmdGetTip (FXObject *, FXSelector, void *) |
| long | onQueryHelp (FXObject *, FXSelector, void *) |
| long | onQueryTip (FXObject *, FXSelector, void *) |
| FX7Segment (FXComposite *p, const FXString &text, FXuint opts=SEVENSEGMENT_NORMAL, FXint x=0, FXint y=0, FXint w=0, FXint h=0, FXint pl=DEFAULT_PAD, FXint pr=DEFAULT_PAD, FXint pt=DEFAULT_PAD, FXint pb=DEFAULT_PAD) | |
| Create a seven segment display. | |
| virtual FXint | getDefaultWidth () |
| Return default width. | |
| virtual FXint | getDefaultHeight () |
| Return default height. | |
| void | setText (const FXString &text) |
| Set the text for this label. | |
| FXString | getText () const |
| Get the text for this label. | |
| void | setTextColor (FXColor clr) |
| Change text color. | |
| FXColor | getTextColor () const |
| Return text color. | |
| void | setCellWidth (FXint w) |
| Get/set cell width. | |
| FXint | getCellWidth () const |
| void | setCellHeight (FXint h) |
| Get/set cell height. | |
| FXint | getCellHeight () const |
| void | setThickness (FXint t) |
| Get/set segment thickness. | |
| FXint | getThickness () const |
| void | set7SegmentStyle (FXuint style) |
| Change 7 segment style. | |
| FXuint | get7SegmentStyle () const |
| Get current 7 segment style. | |
| void | setJustify (FXuint mode) |
| Set the current text-justification mode. | |
| FXuint | getJustify () const |
| Get the current text-justification mode. | |
| void | setHelpText (const FXString &text) |
| Set the status line help text. | |
| const FXString & | getHelpText () const |
| Get the status line help text. | |
| void | setTipText (const FXString &text) |
| Set the tool tip message. | |
| const FXString & | getTipText () const |
| Get the tool tip message. | |
| virtual void | save (FXStream &store) const |
| Save to a stream. | |
| virtual void | load (FXStream &store) |
| Load from a stream. | |
Protected Attributes | |
| FXString | label |
| FXColor | textColor |
| FXint | thickness |
| FXint | cellwidth |
| FXint | cellheight |
| FXString | tip |
| FXString | help |
Seven-segment (eg LCD/watch style) widget, useful for making indicators and timers.
Besides numbers, the seven-segment display widget can also display some letters and punctuations.
|
